REFERENCE: 52-067
Confidence Monitor I/O Enclosure Box w/2 Blank Punches
This is the standard IO box we use for our confidence monitor caddies. The box is designed for customers who are only using a single video input source with their system. The box features a laser etched, text “video” label above the left d-punch. The right punch features a white blank box allowing users to either write a label or use a label machine to notate the connector. The right punch comes standard with an anodized blank plate. D-series connectors are available from LM. Don’t forget to complete your system with a HD LM Tour Systems power cable!
To purchase this box from our online store, CLICK HERE.
- REFERENCE: 52-067
- CATEGORY: Custom Integration
