Products
Portable iPad Sync/Charge Case
The iPad Sync/Charge Station is designed to store, charge, sync and transport 36 iPads. The case features 36 individual slots, with individual cables that accommodate each device. All equipment was spec'd and installed by LM's in house Custom Integration department.
Waterproof Sideline Workbox
This case is designed to be a waterproof mobile storage solution for harsh environmental conditions. The drawers are built into a free standing unit then shock isolated from the exterior case to provide an extremely durable road worthy design. The drawers and interior unit are built out of 1/2" marine grade plastic, each drawer features a black powder coated handle and a 3/8" Lexan lid that contains the contents of each drawer when the case is traveling on its wheels.
Locker Room Workbox
The Locker Room Workbox is designed with ergonomics and fast deployment in mind. The trunk only has one removable lid, which magnetically stores on the back of the trunk for one less thing to trip on in a locker room. The top hinged lid features a storage compartment for a cordless drill, 6 – 3 compartment tilting bins and the drill's battery charger. The work surface is laminated with black Formica and features a recessed 6 outlet power strip that is wired to a retractable 30ft extension cord. Below the work surface are 6 black texture coated drawers mounted on HD Accuride glides for storage.
Deluxe Laundry Trunk
The Deluxe Laundry trunk is designed to be the ultimate road worthy travel solution for your players dirty laundry. The trunk is constructed out of 1/2" marine grade plastic and is designed to be hosed out after messy games. The trunk is split into 2 sides; each with a hanging clothes section, dirty laundry trap door and a slide out drawer. Each hanging clothes section is designed to be loaded with clean clothes on hangers, once the coaches are dressed the case can be closed. The trap doors that access each hanging clothes section are designed to act as hamper doors allowing coaches to simply walk by and toss their dirty laundry in; the dirty clothes are held in by 3/8" clear Lexan doors.
Portable Video Fly-Pack Case
This case was designed to be a portable pre-wired video fly pack. The case features dual 24" Dell Ultrasharp monitors, dual 4 space shock mounted racks, a stationary work surface, a retractable switcher work surface, and dual 9 space shock mounted racks below the switcher.
FOH Chair Case
This case was built for Volt Lites. The case is designed to store the rolling chair and support items used during shows. The chair compartment is lined with 1" PE foam covered with white HDPE plastic to allow the chair to slide in and out without damaging the foam. Below the chair compartment is a large drawer mounted on HD Accuride glides. There is also a storage compartment in the lid to hold a table.
Behringer X32 ATA Workstation
This case was designed for Digerati Audio Visual Systems. The case is designed to be used for fixed installation applications where the workstation needs to be removed from a closet and plugged into a house PA system.
90 Capacity iPad Charging Case
This case was designed for the Philadelphia Eagles by the LM Cases Custom Integration department. The case features 90 individual compartments with custom cables to charge the teams iPads when they are on the road. The case is designed to be locked while the iPads are charging inside.
Midas Venice F16R Case
This case is designed for the rackmounted version (F16R) of the Midas Venice F16 mixing console. The case features angled foam blocks that contour the rack ears of the console and trap it in the case without touching the knobs or faders. The case tray features plastic strips the prevent the feet from sinking into the foam. The exterior case is built out of 1/4" plywood (thicker plywood is available on request) to keep it as lightweight as possible. The console can be used in the case tray.
Waterproof Coles 4038 Microphone Case
This case was designed for Washington & Lee University for a Coles 4038 mic. The mic is cradled in a custom CNC cut foam insert that contours the mic and attached stand mount at different elevations to ensure maximum protection. The foam insert also accommodates the 4069 3 pin to XLR adapter. The foam insert is housed in a Pelican 1300 waterproof case.
GrandMA2 FOH Workstation Case
This case was designed for Volt Lites by the LM Cases Custom Integration Department to be a fully integrated front of house workstation for large scale tours. The LM Cases CI department handled the sale and installation of many of the case components such as the video monitors, audio monitors, mounts, custom cables, and rack mounted components.
The case design is centered around the GrandMA 2 Fullsize lighting console which is mounted on a retractable shelf. Because each show is programmed and run from the console, the case needed to have 2 distinct "Live" and "Program" modes. In Live Mode, the console is retracted over the case and the 2 monitors are moved over the audio monitors so the operator can see the stage. In Program Mode, the console can be extended from the case allowing the programmer to sit with their legs under the console like a traditional desk. The console sits on 4 pedastals that hold it by its feet to keep it firmly in place during use and provide additional shock protection during transport. The console is also held by 2 lid mounted dividers that separate the console from the speaker enclosures. The pedastals are made out of PE foam and marine grade plastic. The monitors can also be move over the rear of the console for maximum visibility. The LM Cases CI department created a Powercon inlet and custom cable to allow the console to be powered via the locking Powercon connectors.
The Dell 23" LCD monitors are mounted on articulating arms allowing them to swing over the console and monitors and be spun between portrait and landscape modes. The video switching between computers, the console and media servers is handled by a 4 in 4 out video switcher.
The audio playback system is based around a 2.1 KRK speaker system compromised of 8" monitors and a 10" subwoofer. Custom black texture coated foam lined enclosures were created to hold the 8" monitors allowing all components to be firmly mounted during transport.
All rack mounted equipment is housed in a 11RU shock mounted double wide rack under the console. The rack section is built out of 1/2" plywood laminated with silver abs plastic allowing a more reflective surface in case equipment needs to be serviced during a show. Cooling is provided by 9 fans pulling air from the outside and cooling both rack sections as well as the computer section to the right of the rack.
The exterior case is built out of 1/2" plywood and features 4" x 2" Colson casters, deep recessed hardware and a 2 color silkscreen of the Volt Lites logo. The top lid has 4 recessed D-Ring shackles mounted in it to allow a table to be strapped to the top of the case during transport. Because the case will be forklifted on to a FOH platform, LM Cases custom 1/4" aluminum forklift guard was employed. The forklift guard is contours the aluminum corner stock of the case and wraps under to provide extra protection when the case is lifted.
Special thanks to Matt and the Volt Lites team!
United Sound 8 Drawer Audio Workbox
This case was designed for United Sound & Electronics. The case is built out of 1/2" plywood and features 8 drawers built out of 1/2" Baltic Birch, the drawers are built into a 1/2" inner shell isolating them from the outer case. The inner shell prevents the drawer glides from being damaged from pulling on the handles or any impacts. Each drawer is treated with our black texture coating to provide a durable surface for abuse on the road. One drawer features a 30 capacity microphone insert that was CNC cut from Ester foam.
Deluxe Coaches Trunk w/Phone Charging Drawer
This trunk was designed for Middle Tennessee State University. The trunk features a hanging clothes section to allow clean clothes to be hung on the way to a game, the compartment also features an external trap door and an internal 3/8" Lexan door allowing coaches to toss dirty clothes into the side of the case without the need for the case to be open.
Baylor University Sideline Workstation
This trunk was designed for Baylor University. The trunk is used on the teams sideline during games for quick repair to equipment between plays and for general storage. The trunk features a black Formica laminated worksurface and 6 drawers mounted on heavy duty Accuride drawer glides. All drawers are built out of 1/2" Baltic birch and black texture coated for a very strong and road worthy design. Mounted above the worksurface is a 24 drawer small parts bin in addition to a Rigid drill and charger.
iMac Production Workstation
This case was built for Starlight Visual. The case is designed to be a self contained mobile lighting production solution that is plug and play. The LM Cases Custom Integration (CI) department installed and provided many of the electronic components including the 2RU i/o panel, keyboard, mouse, rack drawer, rack shelf, powerstrips and electrical connections prior to shipment to Starlight Visual for the final assembly.
